Model Number: CST2D2UP

Metal Curve Profile Universal LED – 2G 2 Way 200W Dimmer Switch – Rotary Push – Leading or Trailing Edge

2 Way switching control
Minimum dimming level adjustable switch available
For Tungsten Lamp: Min.10W to Max.200W
For Halogen Lamp: Min.10W to Max.200W
For Dimmable LED Lamp : Min.5W to Max.150W
Note: To operate at the LED lamps, the light bulb or the driver/control gear must be competitable with dimmable function. It is not suitable to use for the non-dimmable type products.
Manufactured to BS Standard
CE, EMC and RoHS certified
Meets all UK and EU Regulations
Dimensions: 87.5mm (W) x 87.5mm(H)
Stainless Steel

SKU: CST2D2UP Categories: , ,

Description

Decorative raised profile design in Stainless Steel finish
Metal front plate and rocker switch made with high quality steel material
Constructed from high temperature resistant thermoset material
This dimmer is protected against overload and auto reset after the overload is removed and the dimmer switched off and back on.
Noise free openation
Integral gasket for moisture protection
Includes mounting screws for easy installation
Fits easily and quickly into 25mm to 47mm back boxes
Full fitting instructions for simple installation
Available with black or white inserts
